| Cat.No. | Size | Nominal Outside | Nominal Wall Thickness | Approx.Wt.Per 100 Ft.(30.5M) |
Qty.In Master Bundle |
||||
| US | in. | mm | in. | mm | Ib. | kg | ft. | pcs | |
| RAC15 | 1/2 | 0.84 | 21.3 | 0.104 | 2.6 | 28.1 | 12.7 | 2500 | 250 |
| RAC20 | 3/4 | 1.05 | 26.7 | 0.107 | 2.7 | 37.4 | 17.0 | 2500 | 250 |
| RAC32 | 1 | 1.315 | 33.4 | 0.126 | 3.2 | 54.5 | 24.7 | 2000 | 200 |
| RAC40 | 1-1/4 | 1.66 | 42.2 | 0.133 | 3.4 | 71.6 | 32.5 | 1000 | 100 |
| RAC50 | 1-1/2 | 1.9 | 48.3 | 0.138 | 3.5 | 88.7 | 40.2 | 1000 | 100 |
| RAC60 | 2 | 2.375 | 60.3 | 0.146 | 3.7 | 118.5 | 53.8 | 450 | 45 |
| RAC75 | 2-1/2 | 2.875 | 73 | 0.193 | 4.9 | 187.5 | 85.0 | 300 | 30 |
| RAC80 | 3 | 3.5 | 88.9 | 0.205 | 5.2 | 246.3 | 111.7 | 200 | 20 |
| RAC90 | 3-1/2 | 4 | 101.6 | 0.215 | 5.5 | 295.6 | 134.1 | 200 | 20 |
| RAC100 | 4 | 4.5 | 114.3 | 0.225 | 5.7 | 350.2 | 155.8 | 200 | 20 |
| RAC125 | 5 | 5.563 | 141.3 | 0.245 | 6.2 | 478.9 | 217.2 | 80 | 8 |
| RAC150 | 6 | 6.625 | 168.3 | 0.266 | 6.8 | 630.4 | 285.9 | 60 | 6 |
